Intellinet

Gigabit RJ45 Copper SFP Transceiver Module

Name: Gigabit RJ45 Copper SFP Transceiver Module
Brand: Intellinet
SKU: 523882
Price: 99.9 EUR
Availability: InStock

1000Base-T (RJ45) port, 100 m (328 ft.)

SKU: 523882

Highlights

Fits any Intellinet Gigabit Ethernet switch with SFP module slots, or any MSA or Cisco compliant SFP port
10/100/1000 Mbps auto-sensing Gigabit Ethernet RJ45 port with Auto MDI/MDI-X support
Adds a Gigabit Ethernet copper connection to a network switch or media converter that supports SFP transceivers

[ view high resolution images ]

Turn a SFP transceiver module slot into a 10/100/1000 Mbps RJ45 copper Ethernet port

The Intellinet Network Solutions Gigabit RJ45 Copper SFP Optical Transceiver Module is built to comply with the MSA (Multi-Source Agreement) standards and offers a cost-effective way to add a Gigabit copper Ethernet port to your SFP enabled network switch.

Compatibility

Compatibility in your network is everything, and the Intellinet Network Solutions SFP Transceiver Module (model 523882) delivers. Use it with any Intellinet Network Solutions SFP equipped network switch or any other MSA compliant SFP enabled switch. And since the Intellinet Network Solutions SFP transceiver module is set to broadcast the vendor pn GLC-T, compatibility to your Cisco gear is provided.

Hot-Pluggable

The Intellinet Network Solutions Gigabit RJ45 Copper SFP Optical Transceiver Module (model 523882) is fully hot-pluggable, and that allows you to install the module without rebooting your network switch for uninterrupted network traffic.

Fits any Intellinet Gigabit Ethernet switch with SFP module slots, or any MSA or Cisco compliant SFP port
10/100/1000 Mbps auto-sensing Gigabit Ethernet RJ45 port with Auto MDI/MDI-X support
Adds a Gigabit Ethernet copper connection to a network switch or media converter that supports SFP transceivers
Distance support: up to 100 m (328 ft.)
Compliant with the SFP Multi-Source Agreement (MSA)
Equivalent to the Cisco GLC-T transceiver
SFP standard form factor
Low power dissipation (1.05 watts typical)
Low EMI due to fully metallic housing
Up to 1.25 Gbps bi-directional communication
Supports hot-plugging
Fully NDAA-compliant
Three-Year Warranty

IEEE 802.3 (Twisted Pair Ethernet)
IEEE 802.3u (Twisted Pair/Fiber Optic Fast Ethernet)
IEEE 802.3ab (Twisted Pair Gigabit Ethernet)

General
Media support:
- 1000Base-T Cat5e or higher UTP/STP RJ45
- 10/100Base-TX - 10/100Base-TX Cat3 or higher UTP/STP RJ45
Connector: RJ45 SFP port
Distance: 100 m (328 ft.)
Design: SFP (Small Form Factor Pluggable), 1.25 Gbps
Cisco GLC-T compatible
Certifications: FCC Class B, CE, RoHS, UKCA, NDAA

Compatible Brands
Cisco, Intellinet Network Solutions, ZyXEL, Linksys, TP-Link, Ubiquiti, D-Link, Edimax, Allnet, Allied Telesis, Digitus, KTI Networks, LevelOne, PLANET, Tenda, TRENDnet, ZTE, Avaya, Mikrotik, Enterasys, Finisar, Dell Force10, Riverstone, Fortinet and more

Power
Power requirement: 3.3 V
Power consumption: 1.2 Watts (maximum)

Environmental
Dimensions (L x W x H): 66 x 13.6 x 14 mm (2.6 x 0.54 x 0.55 in.)
Weight: 20 g (0.71 oz.)
Operating temperature: 0 – 70°C (32 – 158°F)
Operating humidity: 10 – 85% RH, non-condensing
Storage temperature: -40 – 85°C (-40 – 185°F)

Package Contents
Gigabit RJ45 Copper SFP Transceiver Module
