Intellinet

High Performance Network Cable

High Performance Network Cable

S/FTP 26 AWG, CAT7 Raw Cable, CAT6a Modular plugs, 10 m, Green

SKU: 741071

Highlights

  • Cat7 600 MHz Cable
  • S/FTP & AWG 26
  • CAT6a RJ45 plug, gold-plated contacts
  • Available in: 04/2024
[ view high resolution images ]

Cat7 raw cable with Cat6a modular plugs gives the best performance for your network infrastructure.Why CAT6a modular plugs?As there is no official, agreed-upon standard for the Cat7 plug, Intellinet Network Solutions uses the highest official TIA/EIA-approved components to give you the best specification available.

  • Cat7 600 MHz Cable
  • S/FTP & AWG 26
  • CAT6a RJ45 plug, gold-plated contacts
  • LSZH Jacket
  • Compatible with T568A and T568B wiring
  • Fully backward compatible with all the previous cable categories, including Category 6a, 6, 5e and 5
  • Lifetime Warranty
    Standards and Certifications
  • CE
  • RoHS
  • REACH

    Standards and Certifications
  • CE
  • RoHS
  • REACH

  • Cat7 raw cable with Cat6a modular plugs
  • S/FTP: S = braid shielded; FTP = foiled twisted pair: an aluminum foil screen around each pair (aluminum-Mylar, referred to as PIMF)
  • LSZH Jacket (Low Smoke Zero Halogen)
  • Guaranteed 100% copper pairs
  • Suitable for 10 Gigabit (10/100/1000/10000 Mbit) networks
  • EIA/TIA 568B

  • Additional SKUs

    • Amazon ASIN: B073PV2K82
    • EAN: 0766623741071
    • UPC: 766623741071
    • ALSO: 2874660

  • Physical Specifications

    • Product net weight: 0.31 kg
    • Product gross weight: 0.32 kg
    • Dimensions: 10 m
    • Packaging type: Bag
    • Packaging dimensions: 250 x 300 x 35 [mm]
    • Master Carton Quantity: 40
    • Master Carton Weight: 13.40 kg
    • Master Carton Dimensions: 490 x 300 x 320 [mm]
  • Datasheet
    • Datasheet     » Download

    • Declaration of Conformity     » Download

View full details
